25 LPM TWO STAGE OIL PURIFICATION MACHINE
| Design Principal |
Mechanical Filtration / Low Vacuum Dehydration |
| Fluid Circulation Rate |
10 LPM / 25 LPM |
| Operating Viscosity |
320 cst (Maximum) / 100 cst (Maximum) |
| Oil Type |
Hydraulic and Mineral Oil |
| Coarse Filter Element Rating |
10μm GF Media |
| Fine Filter Element Rating |
05μm GF Media (Customized) |
| Power Supply |
415V AC 3PH |
| Suction Hose |
25 NB SAE100R1 |
| Discharge Hose |
25 NB SAE100R1 |
| Oil Parameter |
Reduction of Contamination & Moisture |
| Safety Features |
All Safety Interlocks |
70 LPM TWO STAGE OIL PURIFICATION MACHINE
| Design Principal |
Mechanical Filtration / Low Vacuum Dehydration |
| Fluid Circulation Rate |
40 LPM / 70 LPM |
| Operating Viscosity |
320 cst (Maximum) / 100 cst (Maximum) |
| Oil Type |
Hydraulic, Mineral, & Fire-Resistant Oil |
| Coarse Filter Element Rating |
25μm, 10μm GF Media |
| Fine Filter Element Rating |
05μm GF Media (Customized) |
| Power Supply |
415V AC 3PH |
| Suction Hose |
40 NB SAE100R1 |
| Discharge Hose |
40 NB SAE100R1 |
| Oil Parameter |
Reduction of Contamination & Moisture |
| Safety Features |
All Safety Interlocks |
150 LPM TWO STAGE OIL PURIFICATION MACHINE
| Design Principal |
Mechanical Filtration / Low Vacuum Dehydration |
| Fluid Circulation Rate |
150 LPM |
| Operating Viscosity |
320 cst (Maximum) / 100 cst (Maximum) |
| Oil Type |
Hydraulic, Mineral, & Fire-Resistant Oil |
| Coarse Filter Element Rating |
25μm, 10μm GF Media |
| Fine Filter Element Rating |
05μm GF Media (Customized) |
| Power Supply |
415V AC 3PH |
| Suction Hose |
50 NB SAE100R1 |
| Discharge Hose |
50 NB SAE100R1 |
| Oil Parameter |
Reduction of Contamination & Moisture |
| Safety Features |
All Safety Interlocks |
